ELECTRONIC NURSE-CALL SYSTEMS 2010 & 8010 SERIES :

Medisystems manufactures a wide range of electronic nurse-call systems. These systems are modular and can be configured for establishments from very small nursing homes to large institutional hospitals. Extremely sturdy, the oldest installed are fully functional even after more than 20 years of continuous use. Based on a simple Red-Yellow-Green signaling principle, present models incorporate a host of additional features including emergency alarm alerts, nurse presence registration, patient-nurse intercom, hospital wide code-blue alarms, call response monitoring, attendant calls, instrument alarm relays, and I-V sensors. They comprehensively address every aspect of nurse-call and require no special training to understand or operate


-----------------------------------------------------------------------------------------------------------------------------------------------------------------
CENTRAL NURSE STATION DISPLAYS :
Large easy-to-read room nos. & emergency messages.
Single button call acknowledgement.
Patient-Nurse Intercom.
Call Transfer and Corridor Slave displays.
Nurse-Call Response Monitoring with reports.
Dimensions : 350 mm L x 350 mm W x 250 mm H
-----------------------------------------------------------------------------------------------------------------------------------------------------------------
BED UNITS :
Lamp indicators for call status.
Nurse help requests.
Instrument alarm relays.
Code-Blue Alerts.
Concealed or Surface mountable box
Dimensions : 90 mm L x 150 mm W x 50 mm H
-----------------------------------------------------------------------------------------------------------------------------------------------------------------
PATIENT HANDSETS :
Rugged handsets with lamp indicators for Normal calls.
Provision for attendant and calls.
Patient-Nurse Intercom.
Lighting, Audio and TV controls.
Dimensions : 175 mm L x 40 mm W x 20 mm H
-----------------------------------------------------------------------------------------------------------------------------------------------------------------
EMERGENCY ALERT UNITS :

Moisture protected, installable within toilets.
Safe, rugged, pull-cord units for shower & bath areas.
Indicator lamps for patient's re-assurance.
Concealed or Surface mountable box
Dimensions : 90 mm L x 150 mm W x 60 mm H
-----------------------------------------------------------------------------------------------------------------------------------------------------------------
DOOR DISPLAYS :
Bright, elegant, three-colour door displays.
Call attendance Registration at room entrance.
Nurse presence indication.
Concealed or Surface mountable box
Dimensions : 150 mm L x 90 mm W x 60 mm H
-----------------------------------------------------------------------------------------------------------------------------------------------------------------
CORRIDOR DISPLAY MODULE :
For an additional display of calling room numbers for hospital corridors.
especially for corridors which are very long and have one or more bends.
Dimensions: 500mm L x 140 mm W x 80 mm H
